Sportsman 570

Sportsman 570

Task To Trail Versatility

*May be shown with additional modifications and/or accessories

BETTER THAN EVER

Delivering performance, reliability, and legendary ride and handling for added comfort from task to trail.


SPORTSMAN 570


{$modelTrimSpecsHeading}
BASE TRIM INCLUDES:
  • 8.2"/9.5" Front/Rear Suspension Travel
  • 25" Tires with 12" Steel Wheels
  • RIDE COMMAND+ with Accessory Purchase
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine

SPORTSMAN 570 EPS


{$modelTrimSpecsHeading}
EPS TRIM INCLUDES:
  •
  • 8.2"/9.5" Front/Rear Suspension Travel
  • 25" Tires with 12" Steel Wheels
  • RIDE COMMAND+ with Accessory Purchase
  • Front CV Guards
  • Multi-Select Electronic Power Steering
  • Front Trail Bumper
  • Braking System (EBS)
  • Dual Taillights
  • Front & Rear Rack Extenders
  •
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine

SPORTSMAN 570 UTILITY HD


{$modelTrimSpecsHeading}
UTILITY HD TRIM INCLUDES:
  • 8.2"/9.5" Front/Rear Suspension Travel
  • 25" Tires with 12" Steel Wheels
  • RIDE COMMAND+ with Accessory Purchase
  • LED POD & Headlights
  • Front CV Guards
  • Utility Front Bumper with Hitch
  • Heavy-Duty Driveline and Sealed Bearings
  • Rear 12 Volt Power Plug
  • Utility Front & Rear Steel Racks
  • Multi-Select Electronic Power Steering (EPS)
  • Easy Effort Throttle, Drive Modes, Geofencing, and Speed Limiter
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine

SPORTSMAN 570 PREMIUM


{$modelTrimSpecsHeading}
PREMIUM TRIM INCLUDES:
  • 8.2"/9.5" Front/Rear Suspension Travel
  • 26" Duro Tires & 14" Aluminum Wheels
  • RIDE COMMAND+ with Accessory Purchase
  • LED POD & Headlights
  • Front CV Guards
  • Active Descent Control (ADC)
  • Engine Braking System (EBS)
  • Multi-Select Electronic Power Steering (EPS)
  • Automotive Style Paint with Custom Graphics Package
  • Front & Rear Rack Extenders
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine

SPORTSMAN 570 TRAIL


{$modelTrimSpecsHeading}
TRAIL TRIM INCLUDES:
  • 8.2"/9.5" Front/Rear Suspension Travel
  • 26" Duro Tires & 14" Aluminum Wheels
  • RIDE COMMAND+ with Accessory Purchase
  • High Output LED Pod & Headlights
  • Front & Rear CV Guards
  • Automotive Style Paint with Custom Graphics Package
  • Active Descent Control (ADC)
  • Engine Braking System (EBS)
  • Multi-Select Electronic Power Steering (EPS)
  • Front Trail Bumper
  • 2,500 Lb. Polaris HD Winch
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine

SPORTSMAN 570 HUNT EDITION


{$modelTrimSpecsHeading}
HUNT TRIM INCLUDES:
  • 8.9"/9.5" Front/Rear Suspension Travel - Arched Dual A-Arm
  • 27" PXT Tires & 14" Aluminum Wheels
  • High Output LED Pod & Headlights
  • Gun Scabbard & Mount
  • Hand & Thumb Warmers
  • Polaris Pursuit Camo Body Work with Custom Graphics Package
  • High Output LED Pod & Headlights
  • 2500 Lb. Polaris HD Winch
  • Front & Rear Trail Bumper
  • Front and Rear Steel Rack Extenders
  • Front & Rear CV Guards
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine

SPORTSMAN 570 RIDE COMMAND


{$modelTrimSpecsHeading}
RIDE COMMAND TRIM INCLUDES:
  • 8.9"/9.5" Front/Rear Suspension Travel - Arched Dual A-Arm
  • 26" DURO Tires & 14" Aluminum Wheels
  • RIDE COMMAND+ with Accessory Purchase
  • 7” Display Powered by RIDE COMMAND
  • High Output LED Pod & Headlights
  • Front & Rear CV Guards
  • 3,500 Lb. Polaris HD Winch with Synthetic Rope and Auto Stop
  • Front Trail Bumper
  • Front and Rear Rack Extenders
  • Multi-Select Electronic Power Steering (EPS)
570 STANDARD FEATURES:
  • On-Demand All-Wheel Drive
  • 11.5" Ground Clearance
  • Factory-Installed Hitch Receiver
  • 1,350 Lb. Towing Capacity
  • Combined 270 Lb. Front & Rear Rack Capacity
  • 44 HP Engine
Specifications
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection / 340 CCA
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Not Equipped
Cooling
Liquid
Front Suspension
Sealed MacPherson Strut With 8.2 in (20.8 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
25 x 8-12; 489
Rear Tyres
25 x 10-12; 489
Wheels
12 in. (30.5 cm) Steel
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
701 lb (318 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage
Electronic Power Steering
Not Equipped
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
Halogen Pod & Bumper Lights, Triple 50w High Beams, Dual 50w Low Beams, Single LED Brake Light/Taillight
{$specsTxt_other_standard_features}
Front Rack Extender, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Winch Mount Included
Variants
Off-road
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection / 340 CCA
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Equipped
Cooling
Liquid
Front Suspension
Sealed MacPherson Strut With 8.2 in (20.8 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
25x8-12 P373; 6 PLY
Rear Tyres
25x10-12 P373; 6 PLY
Wheels
12 in. (30.5 cm) Steel
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
760 lb (345 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage
Electronic Power Steering
Multi Select EPS
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
Halogen Pod & Bumper Lights, Triple 50w High Beams, Dual 50w Low Beams, Dual LED Brake Light/Taillight
{$specsTxt_other_standard_features}
Front Trail Bumper, Front Rack Extender, Rear Rack Extender, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Winch Mount Included, Front A-Arm Guards
Variants
Off-road
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection / 340 CCA
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Equipped
Cooling
Liquid
Front Suspension
Sealed MacPherson Strut With 8.2 in (20.8 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
25x8-12 P373; 6 PLY
Rear Tyres
25x10-12 P373; 6 PLY
Wheels
12 in. (30.5 cm) Steel
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
791 lbs (359 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage, 2 Gal (23L) Under Seat Storage
Electronic Power Steering
Multi Select EPS
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Geofencing, Speed Limiter, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
LED POD High Beam, LED Low Beam Headlights, Dual LED Brake lights/Taillights
{$specsTxt_other_standard_features}
Front Utility Bumper, Front Utility Rack, Rear Utility Rack, Rear Storage Bag, Rear Power Port Plug, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Winch Mount Included, Painted Plastics. Ride Control (Easy Effort Throttle, Speed Limiting, Geofencing, PIN Activated Security System), Front and Rear A-Arm Guards
Variants
Off-road
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection / 340 CCA
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Equipped
Cooling
Liquid
Front Suspension
Sealed MacPherson Strut With 8.2 in (20.8 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
26 x 8-14; DURO
Rear Tyres
26 x 10-14; DURO
Wheels
14 in. (35.6 cm) Aluminum
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
756 lbs (343 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage
Electronic Power Steering
Multi Select EPS
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
LED POD High Beam, LED Low Beam Headlights, Dual LED Brake lights/Taillights
{$specsTxt_other_standard_features}
Front Trail Bumper, Front Rack Extender, Rear Rack Extender, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Winch Mount Included, Painted Plastics, Front A-Arm Guards
Variants
Off-road
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Equipped
Cooling
Liquid
Front Suspension
Sealed Dual A-Arm 8.9 in (22.6 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in. (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
26 x 8-14; DURO
Rear Tyres
26 x 10-14; DURO
Wheels
14 in. (35.6 cm) Aluminum
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
873 lb (396 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage
Electronic Power Steering
Multi Select EPS
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
High Output LED POD High Beam, High Output LED Low Beam Headlights, Dual LED Brake lights/Taillights
{$specsTxt_other_standard_features}
Front Trail Bumper, 2,500 lb. Polaris HD Winch, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Painted Plastics, Front and Rear A-Arm Guards
Variants
Off-road
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection / 340 CCA
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Equipped
Cooling
Liquid
Front Suspension
Sealed Arched Dual A-Arm 8.9 in (22.6 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
26 x 8-14; PXT
Rear Tyres
26 x 10-14: PXT
Wheels
14 in. (35.6 cm) Aluminum
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
866 lb (392.8 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage
Electronic Power Steering
Multi Select EPS
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
Halogen Pod & Bumper Lights, Triple 50w High Beams, Dual 50w Low Beams, Dual LED Brake Light/Taillight
{$specsTxt_other_standard_features}
Front and Rear A-Arm Guards, Front Trail Bumper, Rear Trail Bumper, Front Rack Extender, Rear Rack Extender, 3,500 lb Polaris Winch, Dipped Camo Plastics, Upgraded Wheels & PXT Tires, Kolpin Gun Scabbard & Mount, Kolpin Ratchet Claws, Hand & Thumb Warmers, 12 Volt Power Plug, In Pod Battery Charger
Variants
Off-road
Engine & Drivetrain
Suspension / Brakes / Wheels
Dimensions
Features
Engine Type
ProStar 4-Stroke DOHC Single Cylinder
Cylinders-Displacement
567cc
Horsepower
44 HP
Fuel System
Electronic Fuel Injection / 340 CCA
Transmission / Final Drive
Automatic PVT P/R/N/L/H In-line Shifting
Drive System Type
One Touch On-Demand AWD/2WD
Engine Braking System
Equipped
Cooling
Liquid
Front Suspension
Sealed Arched Dual A-Arm 8.9 in (22.6 cm) Travel
Rear Suspension
Sealed Dual A-Arm, IRS 9.5 in. (24.1 cm) Travel
Front / Rear Brakes
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
Parking Brake
Park In-Transmission / Lockable Hand Lever
Front Tyres
26 x 8-14; DURO
Rear Tyres
26 x 10-14; DURO
Wheels
14 in. (35.6 cm) Aluminum
Front / Rear Rack or Box Capacity
90 lb /180 lb (40.8 kg /81.6 kg)
Fuel Capacity
4.5 gal (17.0 L)
Ground Clearance
11.5 in (29 cm)
Overall Vehicle Size (L x W x H)
83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm)
Payload capacity
485 lb (220 kg)
Person Capacity
1
Wheelbase
50.5 in (128.3 cm)
Dry Weight
883 lbs (400 kg)
Seat Height
33.25 in (84.5 cm)
Cargo System
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage
Electronic Power Steering
Multi Select EPS
Hitch Towing Rating
1,350 lb (612 kg)
Hitch / Type
Standard 1.25 in (3.2 cm) Receiver
Instrumentation
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
Lighting
High Output LED POD High Beam, High Output LED Low Beam Headlights, Dual LED Brake lights/Taillights
{$specsTxt_other_standard_features}
7" Glove Touch Display, Plow Mode, Group Ride, GPS Navigation, Bluetooth, 3,500 lb. Polaris HD Winch with Auto Stop and Synthetic Rope, Front Trail Bumper, Front and Rear Rack Extenders, Painted Plastics, Painted Springs, In Pod USB Charger, PIN Activated Secrity System (P.A.S.S.), Front and Rear A-Arm Guards
Variants
Off-road

STRONG

Relentless, job-ready features for the daily grind.

SMOOTH

Legendary Sportsman suspension delivers the smoothest ride to absorb bumps of all sizes.

  1. 9.5"

    Rear suspension

  2. 11.5"

    Ground clearance

  3. Tame uneven terrain

    Sealed suspension bushings

Suspension

Independent rear suspension delivers more traction and helps you ride over even bigger obstacles.

VERSATILE

Best-in-class integrated storage and smart features for long days out. Plus, you can customize for your work or play needs with a wide selection of accessories.

GALLERY
